Home > Products > Heating > Electric Heating

weekly pre-programmed room Thermostat for heating film

FOB Price:

US 18-23 / Piece

Min.Order Quantity:

1 Piece/Pieces

Supply Ability:

10000 Piece/Pieces per Month

Port:

Shanghai/Nanjing

Place of Origin:

Jiangsu, China (Mainland)

Payment Terms:

T/T,Western Union,Paypal

Brand:

INSBUD

Products Model:

TR3300

Products Details
Company Profile

Quick Details

Brand Name: INSBUD

Model Number: TR3300

Place of Origin: Jiangsu, China (Mainland)

Packaging & Delivery

Packaging Details: 1pc/inner box, 100pcs/carton
Delivery Detail: 1 day

Specifications

TR3300 weekly pre-programmed room Thermostat for heating film
> Large LCD display

> Easy to use and install

> Wall or tabletop mounting

> Extra slim and compact control panel
> Can switch up to 16 amps, (230v AC, 120v Ac available)
> Can be either an air only / floor only / Air & Floor
> 5/2 day and 7 day programmable mode selectable
> Temporay override and vacation mode
> Frost protection function
> With blue back light
> white,silver ,granite finishes
> F / C temperature format can be selected
> 12/24 Hour clock format can be selected
> programmes and settings can be reserved after power break
> equipped with air and floor sensor
> Floor temperature limit
> Adjustable switching differential
> Firmware can be upgraded
> Customizing welcome

Specifications
* Power supply: 230VAC (120VAC optional)
* Inputs: 2 x NTC10K temperature sensors
* Output: 1 x switch relay(R1),max 3500watts
* Ambient temperature: 0 °C [+32 °F] ~ +45 °C [+113 °F]
* Operating RH: 0~95% (non condensing).
* Dimensions: 86mm x 86mm x13mm
* Display Size: 65 x 48mm.
* Backlight life: 5,000 hours.
* Battery type: CR 1220 (Backs up clock only)
* Battery life: > 5years (10 years Maximum)

Dimension

Packing Details

> 1pc/inner box, 100pcs/carton

> Carton size: 55*42*40cm

Wiring Diagram
